Company Profile

Zmotion Introduction

Zmotion Technology -- Better Motion Control, Smarter Life

Welcome~

Nice to meet you.

There is “Shenzhen Zmotion Technology Co., Ltd”.

[Zmotion Technology]


Zmotion is a national high-tech enterprise, which focuses on research and development in motion control technology and general motion control hardware & software products. Products are with ISO9001 and CE certifications.

Founded in 2013, Zmotion  insists self-innovating to research and develop basic and deep knowledge of motion control. Then, service many automation devices and solutions in various applications successfully.

In this way, Zmotion has already become one of the fastest growing industrial motion control companies in China, also it is the rare company that has completely managed core technologies of motion control and real time industrial control software.


[Zmotion Motion Control Products]


A.  Zmotion Various & Powerful Products

*Zmotion Hardware | Motion Controllers*

ü   Multi-Axis Pulse Embedded Motion Controller

ü   Multi-Axis fieldbus EtherCAT Embedded Motion Controller

ü   Multi-Axis Pulse Network Motion Control Card

ü   Multi-Axis fieldbus EtherCAT PCI & PCIE Motion Control Card

ü   Multi-Axis fieldbus EtherCAT Machine Vision Motion Controller

ü   EtherCAT / CAN IO Remote Module

ü   Modbus Teach Pendant, HMI


Motion Controllers & Motion Control Cards: “control pulse stepper motors / control servo motors / drivers of standard EtherCAT protocol”

--ZMC  —   ECI  —   PCI  —   PCIE / XPCIE--

Machine Vision Motion Controllers: “based on motion controllers + machine vision”

--VPLC--

EtherCAT / CAN Expansion Module: “expand axes / IO / AIO by EtherCAT / CAN protocol”

--EIO  —   ZIO  —   ZMIO--

Teach Pendant: “develop interface for motion controller, Modbus protocol”

--ZHD--


*Zmotion Software | Development Software*

ü   Free IDE Motion Control & Machine Vision Development Platform “RTSys”

“RTSys” supports development, debugging, and diagnosis.

“RTSys” can develop motion control and machine vision functions together.

“RTSys” main programming languages are RTBasic, RTPlc, RTHmi, and RTVision.

“RTSys” supports Chines & English by default, also, you can add your own language.

“RTSys” supports small simulation tool inside it (no real controller, test in advance).

l    Download Add.: https://www.zmotionglobal.com/pro_info_282.html

l    Video Description: https://youtu.be/4C3S2n9774A


*Zmotion Solution | Standard System*

ü   3-6 Axis Static / Dynamic / Linkage Dispensing

ü   SCARA & Delta Robotic Arm Loading & Unloading / Welding

ü   Laser Galvanometer | Laser Large-Format Marking, Laser Cutting, etc.

ü   5-Axis Linkage CNC Denture Machine Solution

ü   ……



B.  Zmotion Products Features & Functions


Motion Control Functions

Basic Functions

Ø   Jog / point to point

Ø   Interpolation: linear, circular,   helical, ellipse, spiral, continuous, etc.

Ø   SCARA manipulator algorithm

Ø   Power failure protection and storage

Ø   Simulation / online debugging

Ø   IO / Axis expansion

Ø   ……

Advanced Functions

Ø   S curve acceleration and deceleration –   make the motion smooth

Ø   Hardware PWM output, high-speed   hardware position synchronous output (PSO) for fly-shooting

Ø   Small cycle speed limit

Ø   Synchronous motion

Ø   Motion superposition

Ø   Encoder hardware latch

Ø   Pitch compensation / backflash

Ø   Pulsed-loop

Ø   Multiple other manipulator algorithms:   Delta, turntable, collaborative arm, 6-joint, other specialized types (please   refer to Zmotion Robotic Arm Manual)

Ø   G Code

Ø   Laser Galvanometer

Machine   Vision Functions

Vision Functions of VPLC Vision Motion Controllers

It supports   motion control functions.

Ø   Vision Positioning

Ø   Vision Measurement

Ø   Vision Recognition

Ø   Contour Matching

Ø   Blob Analysis

Ø   QR code / bar code Detection

It supports   HDMI interface, like one Linux / Windows IPC.

Industrial cameras can be these: Mvision, Basler, Mindvision, Huaray, Dvpcamera, Daheng,   etc.

More details,   please refer to “Zmotion   RTVision Manual”



[Zmotion Motion Control Programming]

Zmotion products should you do second-development:

Method 1: PC host computer languages

C++, C#, LabView, Python, etc.

You only need to call uniform API function library and commands. Please refer to Zmotion PC Programming Manual & Examples.


Method 2: RTBasic in RTSys

RTBasic, RTPlc, RTHmi.

These are Zmotion own programming languages, and the platform is RTSys.

Also, call encapsulated commands to complete required actions.

Please refer to Zmotion RTBasic Programming Manual & Examples.

[Zmotion Motion Control Applications]

In motion control automatic field, Zmotion controllers are used widely in China and abroad, covering many corresponding industrials: 3C electronics, Laser Processing, Printing and Packaging, Industrial Robot, Medical Devices, Semi-Conductor Equipment, Special Machine Tool, Stage Entertainment, etc.

Zmotion always puts quality at the first place, regards customer requirements as the first-priority, bases on creating value and pursues improvement of products performance. What we do is to supply smart manufacturing with more valuable motion control products, solutions and services.


“Tips”

n    "Support" & "Download" & “Contact Us” can help you.

n    Others: Youtube  &  LinkedIn    &  Twitter   &  Tiktok   &  Facebook




×
