It supports motion control function and machine vision function
Up to 64 axes motion control (EtherCAT axis / encoder axis / pulse axis / virtual axis)
It supports encoder position measurement, which can be configured as handwheel input mode.
There are 20 NPN inputs, some high-speed inputs can be configured as latch, and some inputs can be used as encoder.
There are 20 NPN outputs, and they are high-speed outputs, some can be configured as hardware comparison outputs, PWM outputs or pulse axes. The max output current can reach 300mA, which can directly drive some solenoid valves. For specified output, the current can reach 2A, which can do light source control output.
There is one 100M EtherCAT bus interface, and 1024 isolated inputs and 1024 isolated outputs can be expanded through EtherCAT bus.
There are 4 USB3.0 interfaces, they can be compatible with USB2.0 and USB1.0 interfaces. And they are mainly used to connect with camera, keyboard, mouse, U disk, and other USB external equipment.
There are 2 COM ports, they can be configured as RS485 serial port / RS232 serial port through DIP switch.
2 / 5 Gigabit ethernet interfaces support multiple kinds of expansion applications, which can connect to PC, camera and other ethernet equipment.
There is one HDMI interface, high-definition display (1080P) is valid.
There is one DVI-D interface, which means standard displayer is supported.
It supports X86 system platform.
It supports max 64 axes linear interpolation, any space circular interpolation, helical interpolation, spline interpolation, etc.
It supports electronic cam, electronic gear, position latch, synchronous follow, virtual axis, etc.
It supports hardware comparison output (HW_PSWITCH2), hardware timer, and precision output in motion.
It supports pulse closed-loop, pitch compensation.
It supports multi-file and multi-task programming in Basic.
It supports a variety of program encryptions to protect user’s intellectual property.
Power-off detection is supported.
